Thick Extra Wide Flange Tapered Plug Caps

XW


Polyethylene Plug Caps with Extra Wide Flange
MOCAP Plastic Stopers with Extra Wide Brim
  • Material: Low-Density Polyethylene (YELLOW)
  • Over-Sized Flanges and High-Visibility for Pre-Assembly Operation Removal
  • Featuring a Wider Flange than the TWF Series for Added Protection of External Surfaces

XW – Media

Thick Extra Wide Flange Tapered Plug Caps Plastic Stopers with Extra Wide Brim Caps with Extra Wide Flange for Hydraulic fittings and Pipes Polyethylene Plug Caps with Extra Wide Flange Thick Extra Wide Flange Tapered Plug Caps MOCAP manufactures and supplies Thick Extra Wide Flange Tapered Plug Caps for product protection. MOCAP stocks Thick Extra Wide Flange Tapered Plug Caps in many sizes for immediate shipment.<br><BR> To place an order, call MOCAP at 800.633.6775.

Size Chart Plastic Stopers with Extra Wide Brim

PrintPrint

XW Size Chart

Default Part # Description Product Line Small O.D.
in
mm
Large O.D.
in
mm
Small I.D.
in
mm
Large I.D.
in
mm
Length
in
mm
Flange OD
in
mm
Box/Mini/Micro
QTY
Buy Online
More info
Default Part # Description Product Line Small O.D.
in
mm
Large O.D.
in
mm
Small I.D.
in
mm
Large I.D.
in
mm
Length
in
mm
Flange OD
in
mm
Box/Mini/Micro
QTY
Buy Online
More info
1 XW.628/.725YW1 XTRA WIDE FLANGE TAPERED PLUG CAP, LDPE YELLOW XW
0.628
16.0
0.725
18.4
0.566
14.4
0.643
16.3
0.440
11.2
2.230
56.6
1000 200 20
2 XW.755/.870YW1 XTRA WIDE FLANGE TAPERED PLUG CAP, LDPE YELLOW XW
0.755
19.2
0.870
22.1
0.686
17.4
0.788
20.0
0.500
12.7
2.370
60.2
1000 200 20
3 XW.867/.975YW1 XTRA WIDE FLANGE TAPERED PLUG CAP, LDPE YELLOW XW
0.867
22.0
0.975
24.8
0.798
20.3
0.889
22.6
0.560
14.2
2.480
63.0
1000 200 20
4 XW.984/1.10YW1 XTRA WIDE FLANGE TAPERED PLUG CAP, LDPE YELLOW XW
0.984
25.0
1.105
28.1
0.909
23.1
1.014
25.8
0.660
16.8
2.610
66.3
1000 200 20
5 XW1.11/1.25YW1 XTRA WIDE FLANGE TAPERED PLUG CAP, LDPE YELLOW XW
1.110
28.2
1.253
31.8
1.046
26.6
1.171
29.7
0.660
16.8
2.730
69.3
500 100 10
6 XW1.23/1.38YW1 XTRA WIDE FLANGE TAPERED PLUG CAP, LDPE YELLOW XW
1.237
31.4
1.382
35.1
1.171
29.7
1.291
32.8
0.660
16.8
2.880
73.2
800 160 16
7 XW1.31/1.46YW1 XTRA WIDE FLANGE TAPERED PLUG CAP, LDPE YELLOW XW
1.312
33.3
1.465
37.2
1.243
31.6
1.375
34.9
0.660
16.8
2.970
75.4
800 160 16
8 XW1.45/1.60YW1 XTRA WIDE FLANGE TAPERED PLUG CAP, LDPE YELLOW XW
1.452
36.9
1.603
40.7
1.387
35.2
1.519
38.6
0.660
16.8
3.100
78.7
700 140 14
9 XW1.58/1.71YW1 XTRA WIDE FLANGE TAPERED PLUG CAP, LDPE YELLOW XW
1.580
40.1
1.714
43.5
1.513
38.4
1.624
41.2
0.660
16.8
3.210
81.5
700 140 14
10 XW1.73/1.90YW1 XTRA WIDE FLANGE TAPERED PLUG CAP, LDPE YELLOW XW
1.735
44.1
1.900
48.3
1.673
42.5
1.838
46.7
0.720
18.3
4.000
101.6
700 140 14
11 XW1.92/2.05YW1 XTRA WIDE FLANGE TAPERED PLUG CAP, LDPE YELLOW XW
1.927
48.9
2.058
52.3
1.867
47.4
1.973
50.1
0.660
16.8
3.560
90.4
600 120 12
12 XW2.12/2.29YW1 XTRA WIDE FLANGE TAPERED PLUG CAP, LDPE YELLOW XW
2.120
53.8
2.290
58.2
2.036
51.7
2.210
56.1
1.000
25.4
3.790
96.3
300 60 6
13 XW2.39/2.60YW1 XTRA WIDE FLANGE TAPERED PLUG CAP, LDPE YELLOW XW
2.395
60.8
2.602
66.1
2.322
59.0
2.530
64.3
1.130
28.7
4.100
104.1
200 40 4
14 XW2.63/2.79YW1 XTRA WIDE FLANGE TAPERED PLUG CAP, LDPE YELLOW XW
2.638
67.0
2.795
71.0
2.547
64.7
2.670
67.8
1.130
28.7
4.260
108.2
200 40 4
Plug To use as a PLUG:
Select a PLUG with a “B” dimension at least .020” (0.5mm) larger than the diameter to be plugged (increase 1% or more for large diameters)
Cap To use as a CAP:
Select a CAP with a “C” dimension at least .020” (.5 mm) smaller than the diameter to be capped (increase 1% or more for large diameters)

Legend:
- Add to Cart - View Price - Request Samples / More Info

Micropacks are only available for purchase through our online store.


Not Quite Sure What You Need? Want to Consider Another Type or a Different Material?
Consult MOCAP's Exclusive Application Advisor for Assistance.



Thick Extra Wide Flange Tapered Plug Caps - Information

MOCAP Thick Extra Wide Flange Tapered Plastic Plug Caps are inexpensive dual function closures which can be used as either a plug or a cap. These tapered polyethylene plug caps are made from tough but flexible polyethylene to form a secure fit, yet are easily removed.
These Plastic Plugs feature flanges which are thick and wider than any of our other plug-cap series. Over-sized flanges and the high-visibility color require removal before assembly operations.
Recommended to use as a cap for tube and hydraulic fittings, tube end caps, pipe caps or product protection. Or use as a plug for threaded holes, openings, fittings and ports.

  • Durable and Flexible - Use as a Cap or Plug
  • Protects Against Debris, Damage, Moisture and Corrosion
  • MOCAP stocks Thick Extra Wide Flange Tapered Plug Caps in many sizes for immediate shipment.


Functions as a Cap
MOCAP's XW Plastic Plug Caps have a tapered design which allow it to be used as a cap for multiple threaded and non-threaded applications.

Functions as a Plug
Use MOCAP XW Tapered Plug Caps to plug a wide range of openings, including threaded and non-threaded holes, pipe and tube end plugs, connector ports and fittings.

Masking Applications
MOCAP Plug Caps can also be used as inexpensive, single use disposable masking caps or masking plugs for painting, coating and spraying processes up to 175°F (80°C).


MOCAP stocks Thick Extra Wide Flange Tapered Plug Caps in many sizes for immediate shipment.

MOCAP now offers Micro-Pack and Mini-Pack quantities when less than case quantities are what you really need. To place an order, click the cart icon on the size chart. Or, to get more information about MOCAP products, call 800.633.6775 or use our Contact Request Form to receive information by e-mail.
