High Temperature Vinyl Tapered Plugs


!!

800.633.6775
Buy Now

High Temperature Vinyl Tapered Plugs

TP-T


Heat Resistant Vinyl Rubber Tapered Masking Cork
MOCAP High-Temp Vinyl Rubber Tapered Stopper
  • Material: High-Temp Vinyl (BLACK)
  • Wide Flange for Easy Removal

TP-T – Media

High-Temperature Vinyl Rubber Plugs High-Temp Vinyl Rubber Tapered Stopper High-Temp Vinyl Plastic Stopper Plug Cap Heat Resistant Vinyl Rubber Tapered Masking Cork High Temperature Vinyl Tapered Plugs High-Temperature Vinyl Rubber Plugs MOCAP provides high temperature tapered plugs for masking applications. Our TP-T Series of plastic plugs are made of vinyl and can be used to seal threaded and non-threaded hole plug openings. To receive plastic plug samples, Contact MOCAP Sales at 1-800-633-6775.

Size Chart

PrintPrint

TP-T Size Chart

Default Part # Description Product Line To Fit STD Thread To Fit METRIC Thread Large O.D.
in
mm
Box/Mini/Micro
QTY
Buy Online
More info
1 TP9211T TP-1 HT TAPERED PLUG TP-T 6-32, 8-32, 10-24 M4, M5
0.250
6.4
5100 1020 102
2 TP9212T TP-2 HT TAPERED PLUG TP-T 1/4 - 20 M6, M7
0.313
7.9
5340 1068 107
3 TP9213T TP-3 HT TAPERED PLUG TP-T 5/16 - 18, 3/8 - 16 M8, M10
0.438
11.1
5175 1035 104
Wall thickness is measured approx. ¼” (6.35mm) from open end. Wall thickness increases slightly towards the closed end of the part
Legend:
- Add to Cart - View Price - Request Samples / More Info

Micropacks are only available for purchase through our online store.


Not Quite Sure What You Need? Want to Consider Another Type or a Different Material?
Consult MOCAP's Exclusive Application Advisor for Assistance.



High Temperature Vinyl Tapered Plugs - Information

MOCAP High Temperature Vinyl Plastic Tapered Masking Plugs are another quality low cost answer to your masking needs. Flexible material allows these plastic plugs to seal threaded and non-threaded openings. Special high temperature resistant vinyl material withstands up to 475°F (246°C).

High temperature resistant Tapered Plugs are available in sizes to fit 6-32 through 3/8-16 standard threaded holes and M4 through M10 metric threaded holes.

High temperature vinyl Insertion Plugs and Nut Plugs also available.
  • Special High Temperature Resistant Plastic Material
  • Standard Round and Pull Tab Cap Designs Also Available




RoHS


Diagram
MOCAP provides high temperature tapered plugs for masking applications. Our TP-T Series of plastic plugs are made of vinyl and can be used to seal threaded and non-threaded hole plug openings. To receive plastic plug samples, Contact MOCAP Sales at 1-800-633-6775.
