Vinyl Plastic Insertion Plugs


!!

Buy Now

Vinyl Plastic Insertion Plugs

MCP


Flexible Plastic Stopper
MOCAP Plastic Plug End Caps
  • Material: Vinyl
  • Flexible Yet Durable - Won't Split, Tear or Shred
  • Wide Flange for Easy Removal
  • Stretches for a Snug Fit but Won''t Split, Tear or Shred

MCP – Media

Vinyl End Plugs Plastic Plug End Caps Plastic Vinyl Plugs Flexible Plastic Stopper Vinyl Plastic Insertion Plugs MOCAP provides vinyl insertion plugs that can be used for shipping and masking applications and for thread protection. Our MCP Series of vinyl insertion plugs can protect valves, pumps, cylinders, tubing and more. To place an order for MOCAP’s plastic plugs, call 800.633.6775.

Size Chart

PrintPrint

MCP Size Chart

Default Part # Description Product Line To Fit METRIC Thread To Fit STD Thread To Fit NPT Flange OD
in
mm
Box/Mini/Micro
QTY
Buy Online
More info
1 MCP9252 MCP-05 INSERTION PLUG MCP M6 1/4
0.400
10.2
5280 1056 106
0.0159 to 0.0336
2 MCP9253 MCP-1 INSERTION PLUG MCP M8 5/16
0.460
11.7
5280 1056 106
0.0159 to 0.0336
3 MCP9254 MCP-2 INSERTION PLUG MCP M10 3/8 1/8
0.495
12.6
5280 1056 106
0.0167 to 0.0348
4 MCP9255 MCP-25 INSERTION PLUG MCP M12 7/16
0.550
14.0
5040 1008 101
0.0168 to 0.0349
5 MCP9256 MCP-3 INSERTION PLUG MCP M14 1/2 1/4
0.620
15.7
5100 1020 102
0.0169 to 0.035
6 MCP9257 MCP-35 INSERTION PLUG MCP M16 9/16
0.683
17.3
5200 1040 104
0.0181 to 0.0358
7 MCP9258 MCP-4 INSERTION PLUG MCP M18 5/8 3/8
0.807
20.5
5120 1024 103
0.0202 to 0.0385
8 MCP9259 MCP-5 INSERTION PLUG MCP M20 3/4 1/2
0.961
24.4
5320 1064 107
0.0231 to 0.0415
9 MCP9260 MCP-55 INSERTION PLUG MCP M22/24 7/8
1.058
26.9
5200 1040 104
0.0285 to 0.0473
10 MCP9261 MCP-6 INSERTION PLUG MCP M26/28 1-1/16 3/4
1.245
31.6
2552 510 51
0.0346 to 0.0537
11 MCP9262 MCP-7 INSERTION PLUG MCP M32/43 1-1/8, 1-3/16, 1-1/4 1
1.495
38.0
2516 503 51
0.0385 to 0.0583
NOTE: Due to the inherent variability of the dip-molding process, the "Flange OD" may vary by +/-1.6mm (1/16") from the figures shown above.
Wall thickness is measured approx. ¼” (6.35mm) from open end. Wall thickness increases slightly towards the closed end of the part
Legend:
- Add to Cart - View Price - Request Samples / More Info

Micropacks are only available for purchase through our online store.

0.0159 to 0.0583

Not Quite Sure What You Need? Want to Consider Another Type or a Different Material?
Consult MOCAP's Exclusive Application Advisor for Assistance.



Vinyl Plastic Insertion Plugs - Information

MOCAP Vinyl Insertion Plugs are perfect for shipping, masking and thread protectors. Use these plastic plugs to protect valves, pumps, cylinders, tubing and other applications.

Use MOCAP plastic plug as pipe plug, hole plug, masking plug or a lower-cost alternative to a rubber plug.

MOCAP round vinyl plastic plugs are available in sizes to fit 1/4" through 1-1/4" standard threaded holes, M6 through M40 metric openings and 1/8 through 1 NPT openings.

Product Protection
Use our vinyl plastic plugs as durable and inexpensive plugs to protect your product during assembly or shipping.

Masking Applications
MOCAP vinyl plastic plugs are often used as inexpensive and disposable single use masking plugs for painting and coating processes under 300°F. For higher temperatures, consider our High Temperature Vinyl and EPDM Masking Products good to 475°F, or our Silicone Masking Products good to over 600°F.



RoHS


Diagram
MOCAP provides vinyl insertion plugs that can be used for shipping and masking applications and for thread protection. Our MCP Series of vinyl insertion plugs can protect valves, pumps, cylinders, tubing and more. To place an order for MOCAP’s plastic plugs, call 800.633.6775.
