Silicone Rubber Washer Plugs for Threaded and Non-Threaded Hole Protection – MOCAP, Plastic and Rubber Products Manufacturer

Silicone Rubber Washer Plugs

MSWP Series

MOCAP Silicone Rubber Washer Plugs are stocked in many sizes to fit your specific application. Rubber plugs fit and protect threaded and non-threaded holes while the flanges mask the area around the holes. Silicone rubber product plugs withstand high temperatures to 600°F (316C) and are safe for e-coating and powder coat systems. Also ideal for chrome plating. Reusable in many applications. MOCAP's line of rubber masking products includes EPDM and silicone rubber plugs and caps stocked in many sizes for immediate shipment.

Flanged Silicone Rubber Plugs
High Temperature Silicone
Chemical and Temp Resistant EPDM Washer Plugs Also Available

Silicone Washer Plugs application images

MSWP Series Size Chart

Part #	(A) Stem Diameter		(B) Large Diamter		(B) Small O.D.		(D) Flange OD		(E) Length		(F) Bevel Length		(G) Stem Height		(H) Flange Thickness		Box QTY	Mini Pack	Buy NOW
Part #	in	mm	in	mm	in	mm	in	mm	in	mm	in	mm	in	mm	in	mm	Box QTY	Mini Pack	Buy NOW
MSWP3	0.156	3.96	0.094	2.39	0.060	1.52	0.393	9.98	0.098	2.49	0.156	3.96	0.590	14.99	0.118	3.00	5,000	250
MSWP4	0.156	3.96	0.141	3.58	0.078	1.98	0.472	11.99	0.125	3.18	0.156	3.96	0.590	14.99	0.118	3.00	5,000	250
MSWP5	0.156	3.96	0.177	4.50	0.110	2.79	0.472	11.99	0.137	3.48	0.216	5.49	0.590	14.99	0.118	3.00	5,000	250
MSWP6	0.196	4.98	0.208	5.28	0.118	3.00	0.511	12.98	0.137	3.48	0.255	6.48	0.590	14.99	0.118	3.00	2,500	250
MSWP8	0.196	4.98	0.283	7.19	0.156	3.96	0.590	14.99	0.156	3.96	0.313	7.95	0.590	14.99	0.118	3.00	2,500	250
MSWP10	0.236	5.99	0.346	8.79	0.177	4.50	0.787	19.99	0.156	3.96	0.472	11.99	0.590	14.99	0.118	3.00	2,500	250
MSWP12	0.236	5.99	0.417	10.59	0.216	5.49	0.866	22.00	0.156	3.96	0.551	14.00	0.590	14.99	0.118	3.00	2,500	250

Samples

MOCAP stocks silicone rubber masking plugs for E-coating, powder coating, masking and finishing applications. Our MSWP Series of rubber washer plugs are stocked for immediate shipping and come in many sizes to fit and protect threaded and non-threaded holes. To place an order, contact MOCAP at 800.633.6775.

Not Quite Sure What You Need? Want to Consider Another Type or a Different Material?
Consult MOCAP's Exclusive Application Advisor for Assistance.

MOCAP Silicone Rubber Washer Plugs --
