Threaded Plastic Plugs for Straight Thread O-Ring Ports

OPP


Plugs for SAE O-Ring Ports and MIL-MS-33649 Bosses
MOCAP Plastic Bolt for Straight Thread O-Ring Ports
  • Material: Polypropylene (RED)
  • Designed to Provide a Positive Seal on SAE Straight-Thread O-Ring Type Ports and Mil-MS-33649 Bosses
  • Features Molded-In O-Ring Style Bead on the Outside of Head to Seal the Port Face from Oil Leakage

OPP – Media

Fittings for Straight Thread O-Ring Ports Plastic Bolt for Straight Thread O-Ring Ports Straight Thread O-Ring Port Plastic Plug Caps (MS33649) Plugs for SAE O-Ring Ports and MIL-MS-33649 Bosses Fittings for Straight Thread O-Ring Ports Threaded Plastic Plugs for Straight Thread O-Ring Ports Threaded Plugs for Straight Thread O-Ring Ports

Size Chart Threaded Hydraulic Caps and Plugs

PrintPrint

OPP Size Chart

Default Part # Description Product Line To Fit STD Thread Length
in
mm
Flange OD
in
mm
Flange Thickness
in
mm
Box/Mini/Micro
QTY
Buy Online
More info
1 OPP0438RD4 Threaded Plastic Plugs for Straight Thread O-Ring Ports - PLUG FOR 7/16-20 STR THRD O-RING PORT, PP RED OPP 7/16-20
0.320
8.1
0.650
16.5
0.380
9.6
5000 1000 100
2 OPP0500RD4 Threaded Plugs for Straight Thread O-Ring Ports - PLUG FOR 1/2-20 STR THRD O-RING PORT, PP RED OPP 1/2-20
0.320
8.1
0.720
18.3
0.380
9.6
5000 1000 100
3 OPP0562RD4 Plastic Bolt for Straight Thread O-Ring Ports - PLUG FOR 9/16-18 STR THRD O-RING PORT, PP RED OPP 9/16-18
0.360
9.1
0.780
19.8
0.380
9.6
5000 1000 100
4 OPP0750RD4 Straight Thread O-Ring Port Plastic Plug Caps (MS33649) - PLUG FOR 3/4-16 STR THRD O-RING PORT, PP RED OPP 3/4-16
0.400
10.2
0.980
24.9
0.380
9.6
5000 1000 100
5 OPP0875RD4 Plugs for SAE O-Ring Ports and MIL-MS-33649 Bosses - PLUG FOR 7/8-14 STR THRD O-RING PORT, PP RED OPP 7/8-14
0.450
11.4
1.110
28.2
0.380
9.6
2500 500 50
6 OPP1062RD4 Fittings for Straight Thread O-Ring Ports - PLUG FOR 1-1/16-12 STR THRD O-RING PORT, PP RED OPP 1 1/16-12
0.620
15.7
1.310
33.3
0.380
9.6
2500 500 50
7 OPP1312RD4 Plastic MS33649 Fitting - PLUG FOR 1-5/16-12 STR THRD O-RING PORT, PP RED OPP 1 5/16-12
0.620
15.7
1.560
39.6
0.380
9.6
1000 200 20
8 OPP1625RD4 Threaded Hydraulic Caps and Plugs - PLUG FOR 1-5/8-12 STR THRD O-RING PORT, PP RED OPP 1 5/8-12
0.620
15.7
1.880
47.8
0.380
9.6
1000 200 20
Legend:
- Add to Cart - View Price - Request Samples / More Info

Micropacks are only available for purchase through our online store.


Not Quite Sure What You Need? Want to Consider Another Type or a Different Material?
Consult MOCAP's Exclusive Application Advisor for Assistance.



Threaded Plastic Plugs for Straight Thread O-Ring Ports - Information

MOCAP Threaded Plastic Plugs are designed for use on Straight Thread O-Ring Ports. These Threaded Plastic Plugs are knurled for easy use in manual assembly and removal.

They provide positive seal on SAE Straight Thread O-Ring type ports and MIL-MS-33649 bosses. Integrated O-ring type bead seats in the bevel of the port to prevent entrance of debris or contaminants and oil leakage. Seal at outside of knurl protects port face against paint and dirt.

Our OPP Series Threaded Plugs are molded in Red polypropylene plastic and sized to fit Straight Thread O-Ring Ports from 7/16-20 thru 1-5/8-12.

MOCAP stocks Threaded Plastic Plugs for Straight Thread O-Ring Ports in many sizes for immediate shipment.

MOCAP now offers Micro-Pack and Mini-Pack quantities when less than case quantities are what you really need. To place an order, click the cart icon on the size chart. Or, to get more information about MOCAP products, call 800.633.6775 or use our Contact Request Form to receive information by e-mail.





RoHS


Diagram
Threaded Plugs for Straight Thread O-Ring Ports
