Sealing Plugs for Unified/Straight Threads

SPU


UNF Sealing Plugs with Slotted Hex Head
Sealing Plugs for Unified/Straight Threads

SPU – Media

Sealing Plugs for Unified/Straight Threads Plastic Sealing Bolt for UNF Threads UNF Sealing Plug Caps (Polypropylene or Nylon) Plastic Sealing Plugs for UNF Threads UNF Sealing Plugs with Slotted Hex Head Threaded Sealing Plugs Plastic Sealing Plugs Sealing Plug 435 Sealing Plug for Straight Threads
  • Material: Polypropylene (RED), Nylon (Yellow)
  • Designed with Five Complete Threads Plus an Integrated Sealing Lip for a Tight Fit
  • Also Available with a Factory Fit Neoprene O-Ring when a Secure Seal is Required

Size Chart Sealing Plug 435

PrintPrint

SPU Size Chart

Default Part # O-Ring To Fit STD Thread Suggested Applications Flange OD
in
mm
Stem Height
in
mm
Length
in
mm
Color Box/Mini/Micro
QTY
Buy Online
More info
1 SPU0437-20RD4 7/16-20 RED
0.820
20.8
0.350
8.9
0.430
10.9
RED 5000 1000 100
2 SPU0437-20RD4NO 7/16-20 RED
0.820
20.8
0.350
8.9
0.430
10.9
RED 5000 1000 100
3 SPU0500-20RD4 1/2-20 RED
0.900
22.9
0.390
9.9
0.430
10.9
RED 3000 600 60
4 SPU0500-20RD4NO 1/2-20 RED
0.900
22.9
0.390
9.9
0.430
10.9
RED 3000 600 60
5 SPU0562-18RD4 9/16-18 RED
0.980
24.9
0.390
9.9
0.430
10.9
RED 3000 600 60
6 SPU0562-18RD4NO 9/16-18 RED
0.980
24.9
0.390
9.9
0.430
10.9
RED 3000 600 60
7 SPU0625-18RD4 5/8-18 RED
0.980
24.9
0.470
11.9
0.470
11.9
RED 3000 600 60
8 SPU0625-18RD4NO 5/8-18 RED
0.980
24.9
0.470
11.9
0.470
11.9
RED 3000 600 60
9 SPU0750-16RD4 3/4-16 RED
1.020
25.9
0.510
13.0
0.390
9.9
RED 3000 600 60
10 SPU0750-16RD4NO 3/4-16 RED
1.020
25.9
0.510
13.0
0.390
9.9
RED 3000 600 60
11 SPU0875-14RD4 7/8-14 RED
1.330
33.8
0.470
11.9
0.550
14.0
RED 3000 600 60
12 SPU0875-14RD4NO 7/8-14 RED
1.330
33.8
0.470
11.9
0.550
14.0
RED 3000 600 60
13 SPU1062-12RD4 1 1/16-12 RED
1.610
40.9
0.470
11.9
0.550
14.0
RED 1000 200 20
14 SPU1062-12RD4NO 1 1/16-12 RED
1.610
40.9
0.470
11.9
0.550
14.0
RED 1000 200 20
15 SPU1313-12RD4 1 5/16-12 RED
1.650
41.9
0.590
15.0
0.590
15.0
RED 1000 200 20
16 SPU1313-12RD4NO 1 5/16-12 RED
1.650
41.9
0.590
15.0
0.590
15.0
RED 1000 200 20
17 SPU1625-12RD4 1 5/8-12 RED
2.280
57.9
0.590
15.0
0.670
17.0
RED 500 100 10
18 SPU1625-12RD4NO 1 5/8-12 RED
2.280
57.9
0.590
15.0
0.670
17.0
RED 500 100 10
19 SPU0437-20YW5 7/16-20 YELLOW
0.820
20.8
0.350
8.9
0.430
10.9
YELLOW 5000 1000 100
20 SPU0437-20YW5NO 7/16-20 YELLOW
0.820
20.8
0.350
8.9
0.430
10.9
YELLOW 5000 1000 100
21 SPU0500-20YW5 1/2-20 YELLOW
0.900
22.9
0.390
9.9
0.430
10.9
YELLOW 3000 600 60
22 SPU0500-20YW5NO 1/2-20 YELLOW
0.900
22.9
0.390
9.9
0.430
10.9
YELLOW 3000 600 60
23 SPU0562-18YW5 9/16-18 YELLOW
0.980
24.9
0.390
9.9
0.430
10.9
YELLOW 3000 600 60
24 SPU0562-18YW5NO 9/16-18 YELLOW
0.980
24.9
0.390
9.9
0.430
10.9
YELLOW 3000 600 60
25 SPU0625-18YW5 5/8-18 YELLOW
0.980
24.9
0.470
11.9
0.470
11.9
YELLOW 3000 600 60
26 SPU0625-18YW5NO 5/8-18 YELLOW
0.980
24.9
0.470
11.9
0.470
11.9
YELLOW 3000 600 60
27 SPU0750-16YW5 3/4-16 YELLOW
1.020
25.9
0.510
13.0
0.390
9.9
YELLOW 3000 600 60
28 SPU0750-16YW5NO 3/4-16 YELLOW
1.020
25.9
0.510
13.0
0.390
9.9
YELLOW 3000 600 60
29 SPU0875-14YW5 7/8-14 YELLOW
1.330
33.8
0.470
11.9
0.550
14.0
YELLOW 3000 600 60
30 SPU0875-14YW5NO 7/8-14 YELLOW
1.330
33.8
0.470
11.9
0.550
14.0
YELLOW 3000 600 60
31 SPU1062-12YW5 1 1/16-12 YELLOW
1.610
40.9
0.470
11.9
0.550
14.0
YELLOW 1000 200 20
32 SPU1062-12YW5NO 1 1/16-12 YELLOW
1.610
40.9
0.470
11.9
0.550
14.0
YELLOW 1000 200 20
33 SPU1313-12YW5 1 5/16-12 YELLOW
1.650
41.9
0.590
15.0
0.590
15.0
YELLOW 1000 200 20
34 SPU1313-12YW5NO 1 5/16-12 YELLOW
1.650
41.9
0.590
15.0
0.590
15.0
YELLOW 1000 200 20
35 SPU1625-12YW5 1 5/8-12 YELLOW
2.280
57.9
0.590
15.0
0.670
17.0
YELLOW 500 100 10
36 SPU1625-12YW5NO 1 5/8-12 YELLOW
2.280
57.9
0.590
15.0
0.670
17.0
YELLOW 500 100 10
Default Part # O-Ring To Fit STD Thread Suggested Applications Flange OD
in
mm
Stem Height
in
mm
Length
in
mm
Color Box/Mini/Micro
QTY
Buy Online
More info
Legend:
- Add to Cart - View Price

Micropacks are only available for purchase through our online store.


Not Quite Sure What You Need? Want to Consider Another Type or a Different Material?
Consult MOCAP's Exclusive Application Advisor for Assistance.



Sealing Plugs for Unified/Straight Threads - Information

MOCAP Sealing Plugs for Unified/Straight Threads are designed to protect Unified/Straight-threaded ports and fittings from moisture, dust and damage during production, shipping and storage. Five complete threads plus a sealing lip provide a tight fit and secure seal. Can be applied and removed by hand, with a socket wrench, screwdriver or power tool.

Our SPU Series Plugs are:


  • Molded in Red Polypropylene(Standard applications)or
  • Yellow Nylon (offers high resistance against hydraulic fluids, solvents, acids and base alkalines)
  • Sized to fit Unified/Straight Threads from 7/16-20 thru 1-5/8-12.


These Sealing Plugs are also available with a factory-fit Neoprene Rubber O-Ring when a perfect seal is required.


MOCAP stocks Sealing Plugs for Unified/Straight Threads in both Red Polypropylene and Yellow Nylon materials in many sizes for immediate shipment.

MOCAP now offers Micro-Pack and Mini-Pack quantities when less than case quantities are what you really need. To place an order, click the cart icon on the size chart. Or, to get more information about MOCAP products, call 800.633.6775 or use our Contact Request Form to receive information by e-mail.
