EPDM Rubber Washer Plugs
MEWP Series
MOCAP EPDM rubber washer plugs fit and protect threaded and non-threaded holes while the flange masks the area around the holes. Rubber EPDM plugs are chemical resistant and good to 450°F (246C) and can be re-used in many applications.
EPDM Washer Plugs application images
| Part # |
(A)
Stem Diameter |
(B)
Small O.D. |
(C)
Large Diamter |
(D)
Flange OD |
(E)
Length |
(F)
Bevel Length |
(G)
Stem Height |
(H)
Flange Thickness |
Box
QTY |
Mini
Pack |
Buy NOW |
| in | mm | in | mm | in | mm | in | mm | in | mm | in | mm | in | mm | in | mm |
| MEWP3 |
0.156 | 3.96 |
0.060 | 1.52 |
0.094 | 2.39 |
0.393 | 9.98 |
0.098 | 2.49 |
0.156 | 3.96 |
0.590 | 14.99 |
0.118 | 3.00 |
5,000 |
250 |
 |
| MEWP4 |
0.156 | 3.96 |
0.078 | 1.98 |
0.141 | 3.58 |
0.472 | 11.99 |
0.125 | 3.18 |
0.156 | 3.96 |
0.590 | 14.99 |
0.118 | 3.00 |
5,000 |
250 |
|
| MEWP5 |
0.156 | 3.96 |
0.110 | 2.79 |
0.177 | 4.50 |
0.472 | 11.99 |
0.137 | 3.48 |
0.216 | 5.49 |
0.590 | 14.99 |
0.118 | 3.00 |
5,000 |
250 |
|
| MEWP6 |
0.196 | 4.98 |
0.118 | 3.00 |
0.208 | 5.28 |
0.511 | 12.98 |
0.137 | 3.48 |
0.255 | 6.48 |
0.590 | 14.99 |
0.118 | 3.00 |
2,500 |
250 |
|
| MEWP8 |
0.196 | 4.98 |
0.156 | 3.96 |
0.283 | 7.19 |
0.590 | 14.99 |
0.156 | 3.96 |
0.313 | 7.95 |
0.590 | 14.99 |
0.118 | 3.00 |
2,500 |
250 |
|
| MEWP10 |
0.236 | 5.99 |
0.177 | 4.50 |
0.346 | 8.79 |
0.787 | 19.99 |
0.156 | 3.96 |
0.472 | 11.99 |
0.590 | 14.99 |
0.118 | 3.00 |
2,500 |
250 |
|
| MEWP12 |
0.236 | 5.99 |
0.216 | 5.49 |
0.417 | 10.59 |
0.866 | 22.00 |
0.156 | 3.96 |
0.551 | 14.00 |
0.590 | 14.99 |
0.118 | 3.00 |
2,500 |
250 |
|
